PRODUCT DETAILS
PRODUCT DESCRIPTION
- Embedded installation
- Separate IC drive, replaceable, no strobe
- Die-cast aluminum radiator
- High power and high lumens
- High quality COB LED chips
- Comply with LVD, Safe and reliable
Datasheet:-DOWNLIGHT_ MQTL1080X
TECHNICAL DATA
| Electrical parameters | |
| Rated Voltage | 170-240V~ |
| Rated Frequency | 50/60Hz |
| Life Data | |
| Life Time | 25000h |
| Switch Times | >12500 |
| Operation Data | |
| IP | IP20 |
| Operating Temperature | -20°C~+50°C |
| Storage Temperature | -20°C~+60°C |
| Mechanical Data | |
| Housing Material | Die-cast aluminium |
| Cover Material | Tempered glass |
| Other | |
| SDCM | <6 |
| Certification | CB/ROHS |
| Model | Watts (W) | PF | Luminous Flux (lm)
(3000K/ 4000K&6500K) |
Beam Angle | CRI | Dimension (mm) |
| MQTL1080-X/20W | 20W | 0.9 | 1600/1800 | 120° | ≥80 | Ø170*42 |
| MQTL1080-X/30W | 30W | 0.9 | 2400/2700 | 120° | ≥80 | Ø230*50 |
PRODUCT DIMENSION
| Model | L (mm) | H (mm) | C (mm) |
| MQTL1080-X/20W | Ø170 | 42 | Ø140 |
| MQTL1080-X/30W | Ø230 | 50 | Ø200 |
APPLICATION
- Living rooms
- Bedrooms
- Kitchens
- Offices
- Meeting rooms
- Educational spaces
- Hotels and hospitality environments
- General indoor lighting
COUNTRY-SPECIFIC INFORMATION
The Megaman MQTL1080-X is an integrated LED downlight designed for recessed ceiling installation.
Unlike a traditional lamp-and-fitting combination, an integrated LED downlight combines the LED light source and luminaire into a purpose-designed lighting solution.
The MQTL1080-X range is particularly flexible because it is available in 20W and 30W configurations. The different sizes and light outputs allow designers, contractors and property owners to select a version according to the scale and lighting requirements of the space.
