PRODUCT DETAILS
PRODUCT DESCRIPTION
- Ultra-thin shape, simple and beautiful
- Complete size, serialized style shape
- Back-lit, luminous uniform without dark area
- Enough space behind the lamp, easy installation and wiring
- High performance LED chips, high lumen efficiency and low light decay
- Flicker free, effectively protect eyesight
- No UV infrared radiation, no mercury environmental protection
- Save around of 85% less energy
- Low temperature and cooler environment
- High luminous flux, high luminous effciency
TECHNICAL DATA
| Electrical parameters | |
| Rated Voltage | 220-240VAC |
| Rated Frequency | 50/60Hz |
| Life Data | |
| Life Time | 15000h |
| Switch Times | <7500 |
| Operation Data | |
| IP | IP20 |
| Operating Temperature | -20°C~+45°C |
| Storage Temperature | -20°C~+60°C |
| Mechanical Data | |
| Housing Material | Plastic |
| Cover Material | PC |
| Other | |
| SDCM | <6 |
| Certification | CB/ROHS |
| Model | Watts (W) | PF | Luminous Flux (lm)
(3000K/ 4000K&6500K) |
Beam Angle | CRI | Dimension (mm) |
| MXTL1033-Y/15W | 15W | 0.5 | 1200/1350 | 120° | ≥80 | Ø180*25 |
| MXTL1033-Y/24W | 24W | 0.5 | 1920/2160 | 120° | ≥80 | Ø225*25 |
| MXTL1033-Y/30W | 30W | 0.5 | 2400/2700 | 120° | ≥80 | Ø250*25 |
PRODUCT DIMENSION
| Model | L (mm) | H (mm) |
| MXTL1033-Y 15W | Ø180 | 25 |
| MXTL1033-Y 24W | Ø225 | 25 |
| MXTL1033-Y 30W | Ø250 | 25 |
APPLICATION
- Living rooms
- Bedrooms
- Kitchens
- Offices
- Retail stores
- Restaurants and cafés
- Hotels and hospitality environments
- Corridors and hallways
COUNTRY-SPECIFIC INFORMATION
The Megaman LED Straight Downlight MXTL1033-Y is designed to operate with Malaysia’s standard 220–240V electrical system, ensuring compatibility with most residential and commercial installations.
Megaman LED downlights are commonly used across Malaysia in homes, offices, and commercial buildings due to their energy efficiency and reliable lighting performance.
