PRODUCT DETAILS
PRODUCT DESCRIPTION
- Stretch aluminum bracket, high strength
- Excellent heat dissipation performance
- Several surface treatment and color optional
- Messenger wire installation, simple operation
- Two mounting methods, pendant and surface
- Can be continuous stitching (Line/Type L/Type T/Type +)
- Back-lit, luminous uniform without dark area
- High luminous efficiency, up to 110lm/W
TECHNICAL DATA
| Electrical parameters | |
| Rated Voltage | 170-240VAC |
| Rated Frequency | 50/60Hz |
| Life Data | |
| Life Time | 25000h |
| Switch Times | >12500 |
| Operation Data | |
| IP | IP20 |
| Class | Class I |
| Operating Temperature | -20°C~+40°C |
| Storage Temperature | -20°C~+60°C |
| Mechanical Data | |
| Housing Material | AL (White or Black) |
| Cover Material | PC |
| Other | |
| SDCM | <6 |
| Certification | CB/CE |
| Model | Watts (W) | PF | Luminous Flux (lm)
(3000K/ 4000K& 6500K) |
Beam Angle | CRI | Dimension (mm) |
| MDL1018/60W | 60W | 0.9 | 6000/6600 | 120° | ≥80 | 1200*50*50 |
PRODUCT DIMENSION
| Model | L (mm) | W (mm) | H (mm) | Single Box Dimension
(L*W*H)mm |
| MDL1018/60W | 1200 | 50 | 50 | 1211*55*55 |
ACCESSORIES OPTIONAL
APPLICATION
- Offices and workspaces
- Meeting rooms
- Retail stores
- Showrooms
- Educational institutions
- Commercial buildings
- Modern residential interiors
COUNTRY-SPECIFIC INFORMATION
The Megaman LED Pendant Light MDL1018 is designed for Malaysia’s 170–240V electrical system, ensuring compatibility with local installations.
Linear pendant lighting is widely used in Malaysia for:
- Offices and corporate environments
- Retail and commercial spaces
- Educational facilities
- Modern interior design projects
Its efficient performance and sleek design make it a popular choice in Malaysian commercial lighting projects.
